Self Priming Flexible Immpeler Pump
Model50Hz 60 HzPressurePlungerDia. (mm) StrokeLength(mm)PowerkW(HP)Inlet&Outlet SizeConnection Size Flow(lph)Flow(gph)SPMFlow(gph)Flow(lph)SPM(Bar)(Psi)JSZ 6/4061.6 961.9 7.2 115 400 5800 8250.75(1)DN66*12mm(union for weld )JSZ 10/25102.6 3.2 12 250 3625 10JSZ 15/20154.0 4.8 18 200 2900 12J......
Send Inquiry
Product Description
| Model | 50Hz | 60 Hz | Pressure | Plunger Dia. (mm) | Stroke Length (mm) | Power kW(HP) | Inlet&Outlet Size | Connection Size | |||||
| Flow (lph) | Flow (gph) | SPM | Flow (gph) | Flow (lph) | SPM | (Bar) | (Psi) | ||||||
| JSZ 6/40 | 6 | 1.6 | 96 | 1.9 | 7.2 | 115 | 400 | 5800 | 8 | 25 | 0.75(1) | DN6 | 6*12mm (union for weld ) |
| JSZ 10/25 | 10 | 2.6 | 3.2 | 12 | 250 | 3625 | 10 | ||||||
| JSZ 15/20 | 15 | 4.0 | 4.8 | 18 | 200 | 2900 | 12 | ||||||
| JSZ 25/10 | 25 | 6.6 | 7.9 | 30 | 100 | 1450 | 16 | ||||||
| JSZ 40/6.3 | 40 | 11 | 13 | 48 | 63 | 914 | 20 | ||||||
| JSZ 65/4.5 | 65 | 17 | 21 | 78 | 45 | 653 | 25 | DN10 | 10*16mm (union for weld ) | ||||
| JSZ 80/3.6 | 80 | 21 | 25 | 96 | 36 | 522 | 28 | ||||||
| JSZ 110/2.8 | 110 | 29 | 35 | 132 | 28 | 406 | 32 | ||||||
| JSZ 130/2.3 | 130 | 34 | 41 | 156 | 23 | 334 | 35 | ||||||
| JSZ 160/2.0 | 160 | 42 | 51 | 192 | 20 | 290 | 38 | ||||||
| JSZ 190/1.6 | 190 | 50 | 60 | 228 | 16 | 232 | 42 | ||||||
| JSZ 270/1.1 | 270 | 71 | 86 | 324 | 11 | 160 | 50 | DN15 | 15*24mm (union for weld ) | ||||
| JSZ 330/0.9 | 330 | 87 | 105 | 396 | 9 | 131 | 55 | ||||||
| JSZ 400/0.8 | 400 | 106 | 127 | 480 | 8 | 116 | 60 | ||||||
| JSZ 500/0.9 | 500 | 132 | 144 | 159 | 600 | 173 | 9 | 131 | 55 | ||||
| JSZ 600/0.6 | 600 | 159 | 190 | 720 | 6 | 87 | 60 | ||||||
